Niederspannungskabel Typ XKN Alse
Niederspannungskabel Typ XKN Alse
NS-Netzkabel mit massiven Aluminium Sektorenleiter und konzentrischem Leiter aus Kupferdrähte.
Mehr lesenBeschreibung
Beschreibung
Normen
-
ProduktHD 603; IEC 60228
-
NationalASE
Applications
- Underground distribution networks
- Pipe laying and ground laying
- Installation in electrical substations
Construction
- Solid aluminium sector conductor
- XLPE cross-linked insulation
- Assembly of 3 insulated conductors
- Separator tape
- PE belt insulation
- Ceander" concentric conductor in copper wire
- Black PE outer sheath with 2 yellow longitudinal lines
Properties
- Cross-linked insulation with high resistance to high operating temperatures in case of overload and short circuit.
- No release of corrosive gases = safe installation
- Outer sheath made of specially abrasion-resistant PE with low shrinkage rate.
- No interruption of the protective conductor when making a branch
- Halogen-free
Eigenschaften
Eigenschaften
Abmessungen
Abmessungen
Leiterquerschnitt
- mm²
Elektrische Eigenschaften
Elektrische Eigenschaften
Zulässiger Strom in Luft, 30°C - im Dreieck verlegt
- A
Zulässiger Strom in Erde, 20°C - im Dreieck verlegt
- A
